[Kea-users] Parsing Option 82

[Itay Rozenberg]

Greetings


Type 001 – circuit_id - hex, you need to convert it to ascii. (try it on this web site: http://www.rapidtables.com/convert/number/hex-to-ascii.htm )
Type 002 – remote_id - Mac address
Each of them can be hex or mac address.

Try this:
std::string hexToAscii(std::string c) {
        int length = c.length();
        std::string newString;
        for (int i = 0; i < length; i+=2) {
                std::string byte = c.substr(i, 2);
                char chr = (char)(int)strtol(byte.c_str(), NULL, 16);
                newString.push_back(chr);
        }
        return newString;
}



OptionPtr rai = query4_ptr->getOption(DHO_DHCP_AGENT_OPTIONS);
        if (rai) {
                OptionPtr circuit_id_opt = rai->getOption(RAI_OPTION_AGENT_CIRCUIT_ID);
                if (circuit_id_opt) {
                        string cid = hexToAscii(circuit_id_opt->toHexString().substr(2));
                }
        }

For the other one (remote_id) use getOption(RAI_OPTION_AGENT_CIRCUIT_ID).

itay

From: Kea-users [mailto:kea-users-bounces at lists.isc.org] On Behalf Of Gokulakrishnan Gopalakrishnan
Sent: Tuesday, July 4, 2017 2:20 PM
To: kea-users at lists.isc.org<mailto:kea-users at lists.isc.org>
Subject: [Kea-users] Parsing Option 82

I'm trying to print and parse Option 82 but I couldn't understand the format in which it is received. My 'option->toText()' print this
type=082, len=024:,
options:
  type=001, len=014: 01:0c:45:74:68:65:72:6e:65:74:31:2f:32:39
  type=002, len=006: 04:62:73:56:13:bc

Can someone help me to understand this value?

Thanks,
Gokul
