[Kea-users] Kea server can't send ACK packets

[Daniel Garrapucho Levy]

Greetings !

We just installed isc-kea in our server and configured it according to what is instructed in the Documentation.
The server receives DHCP DISCOVERY packages, but it doesn't seem to be able to send back any ACK response.
The only clue we have so far is the log file we configured for dhcp packets :
Given the following variables, this is what we get whenever we simulate a DHCP Discovery broadcast with nmap

  *
AddressCliet: IP address of the client from which we run the tests
  *
AddressServer: IP address of the server where Kea DHCP is installed
  *
MACClient: MAC address of the client from which we run the tests.

Command used from the client: nmap -sU -p67 --script dhcp-discover AddressServer

DHCP4_BUFFER_RECEIVED received buffer from AddressClient:RandomPort to AddressServer:67 over interface NetworkInterface
DHCP4_PACKET_RECEIVED [hwtype=1 MACClient], cid=[no info], tid=0x624894ca: DHCPDISCOVER (type 1) received from AddressClient to AddressServer on interface NetworkInterface
DHCP4_PACKET_SEND [hwtype=1 MACClient], cid=[no info], tid=0x624894ca: trying to send packet DHCPOFFER (type 2) from AddressServer:67 to 255.255.255.255:68 on interface NetworkInterface
DHCP4_PACKET_SEND_FAIL [hwtype=1 MACClient], cid=[no info], tid=0x624894ca: failed to send DHCPv4 packet: pkt4 send failed: sendmsg() returned  with an error: Permission denied


We have already made sure that the subnet we have configured is using the rigth network interface and we have opened both UDP ports 67/68 on the server using ufw, but to no avail. Using udp or raw packets gives the same outcome.

We also checked that the kea sockets directory is owned by user _kea:_kea with mode 0755

This is the information of the server where Kea is installed


OS
Ubuntu 22.04.5 LTS
Kea version
3.0.2
Installation method
Package from Cloudsmith repository


And this is the configuration of the dhcp server service:
[Unit]
Description=ISC KEA IPv4 DHCP daemon
Documentation=man:kea-dhcp4(8)
Wants=network-online.target mariadb.service
Requires=kea-ctrl-agent.service
After=network-online.target mariadb.service mysql.service

[Service]
ExecStart=/usr/sbin/kea-dhcp4 -c /etc/kea/kea-dhcp4.conf
RuntimeDirectory=kea

[Install]
WantedBy=multi-user.target

Any idea what can be wrong ?  Many thanks for the hard work !
